The Ubiquiti UAP-AC-LR Dual-Band Access Point is a high-performance wireless access point that offers Wi-Fi 5 (802.11ac) connectivity on both the 2.4 GHz and 5 GHz bands. It features one internal antenna with a gain of 3 to 6 dBi, providing reliable wireless coverage. With MU-MIMO support for up to 3 x 3 clients, this access point can handle multiple devices simultaneously. The transmit power ranges from 22 to 24 dBm, providing strong signals even at distance. It delivers a total throughput of 1317 Mb/s, split between 450 Mb/s on the 2.4 GHz band and 867 Mb/s on the 5 GHz band.
The access point comes equipped with a single Gigabit Ethernet port for connecting to wired devices. It supports a range of security protocols including AES, TKIP, WEP, WPA, WPA-PSK, and WPA2, ensuring secure wireless connections. The Ubiquiti UAP-AC-LR Dual-Band Access Point can support up to 200 clients and complies with IEEE 802.11i standards. Powered by DC input at 0.5A, it consumes 6.5 watts of power. It operates in temperatures ranging from 14 to 158°F / -10 to 70°C and can function in humid environments with 5 to 95% operating humidity. The device is CE, FCC, and IC certified. Overall, the Ubiquiti UAP-AC-LR Dual-Band Access Point is ideal for small to medium-sized businesses and homes looking for reliable and secure wireless connectivity. It measures 6.9 x 6.9 x 1.7" / 17.6 x 17.6 x 4.3 cm and weighs 0.7 lb / 0.3 kg. The product is available in Techland BD with a package weight of 1.8 lb and box dimensions of 10.75 x 8.9 x 2.75".
Networking & Connectivity | |
Transmit Power |
22 to 24 dBm
|
Max SSIDs Supported |
802.11i
|
Number of Antennas |
1
|
Wi-Fi |
Wi-Fi 5 (802.11ac); Dual-Band (2.4 & 5 GHz)
|
MU-MIMO Support |
3 x 3
|
Antenna Gain |
3 to 6 dBi
|
Wireless Security |
AES, TKIP, WEP, WPA, WPA-PSK, WPA2
|
Antenna Placement |
Internal
|
Throughput |
1317 Mb/s Total
2.4 GHz: 450 Mb/s 5 GHz: 867 Mb/s |
Battery And Power | |
DC Input Power |
VDC at 0.5 A
|
Power Consumption |
6.5 W
|
Ports | |
Inputs/Outputs |
1 x 10/100/1000 Mb/s Gigabit Ethernet (RJ45)
|
Others | |
Operating Temperature |
14 to 158°F / -10 to 70°C
|
Physical Specification | |
Operating Humidity |
5 to 95%
|
Dimension |
6.9 x 6.9 x 1.7" / 17.6 x 17.6 x 4.3 cm
|
Weight |
0.7 lb / 0.3 kg
|
Technical Info | |
Supported Clients |
200
|
