TP-Link VIGI C340S Outdoor Color Pro Night Vision Bullet Network Camera is an advanced security solution designed for high-quality surveillance in all lighting conditions. Featuring a 4MP resolution (2688 × 1520), this camera ensures crystal-clear images with enhanced details. Its F1.0 large aperture lens allows for superior low-light performance, capturing color images even in ultra-dark conditions. Equipped with four powerful white LEDs, the VIGI C340S extends night vision up to 30 meters, ensuring round-the-clock security. The IP67 weatherproof rating makes it durable against harsh weather, making it perfect for both residential and commercial outdoor installations. It supports H.265+ compression, reducing bandwidth and storage usage without compromising video quality. With two-way audio communication, users can both hear and speak through the camera, enhancing real-time interaction and security. The camera includes smart AI detection features, such as human and vehicle classification, intrusion detection, and motion alerts, ensuring that users receive accurate notifications for real threats. Additionally, ONVIF compatibility allows seamless integration with NVRs and security management systems. Whether monitoring your home, office, or business premises, the VIGI C340S provides superior protection with multi-streaming support, secure cloud access, and advanced encryption. Its PoE support simplifies installation, reducing cable clutter. To ensure the best value and authenticity, customers in Bangladesh can purchase the TP-Link VIGI C340S 4MP Outdoor Color Pro Night Vision Bullet Network Camera from Tech Land BD a trusted retailer of networking and security products!
Yes, it features 30m full-color night vision with IR and white LEDs, providing clear footage even in low-light conditions.
Yes, the built-in microphone and speaker allow two-way audio communication for real-time interaction.
No, the VIGI C340S is not rated for waterproofing (N/A for IP protection). However, it is suitable for indoor or covered outdoor installations.
Display | |
Image Sensor |
1/1.8” Progressive Scan CMOS
|
Image |
Image Settings
Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance, Prevent Overexposure to Infrared Light, HLC Adjustable by Client Software Image Enhancement BLC/3D DNR/HLC/SmartIR Wide Dynamic Range - 120 dB SNR - ≥ 52 dB Image Parameters Switch - Yes Privacy Mask - Up to 4 Masks ROI - 1 Region OSD Setting - Yes |
Viewing Angle |
4mm: Horizontal FOV: 95.2°, Vertical FOV: 50.6°, Diagonal FOV: 114.7°
6mm: Horizontal FOV: 57.1°, vertical FOV: 30.2°, Diagonal FOV: 67.2° |
Camera | |
IR Distance |
DORI Distance
4 mm Detect: 70 m (231 ft) Observe: 29 m (96 ft) Recognize: 14 m (46 ft)) Identify: 7 m (23 ft) |
Camera Feature |
Slow Shutter - Yes
Minimum Illumination 0.005 Lux; 0 Lux with IR/white light Day/Night Mechanism - IR Cut Filter Day/Night Switch - Day/Night/Auto/Schedule-Switch |
Aperture |
4 mm: F1.0
6 mm: F1.0 F1.0 (LENS) |
LENS |
Fixed focal lens (4 mm / 6 mm)
|
Lens type |
Fixed Focal Lens
|
Shutter Speed |
1/3 to 1/10000 s
|
Lens Mount |
M16*P 0.5 (Lens)
M12(Camera) |
Focal Length |
4 mm
|
Networking & Connectivity | |
Protocols |
TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS
|
Networks |
ONVIF - Yes
API - Open Network Video Interface (Profile S) Simultaneous Live View - 3 Main Streams & 3 Sub-Streams Client - VIGI App, VIGI Security Manager, VIGI NVR, Web Web Browser - Google Chrome 57 and above Firefox 52 and above - Safari 11 and above Microsoft Edge 91 and above Cloud - Yes Network Storage NAS (NFS, SMB/ CIFS) |
Network Interface |
1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE
|
Audio & Microphone | |
Built-in Mic |
Yes; Records Anything Going on within a 15-ft Radius of the Camera
|
Built-in Speaker |
Yes
|
Audio |
Audio Communication - Yes
Audio Input - Yes Audio Output - Yes Audio Compression - Yes Audio Sampling Rate - 8KHz Environment Noise Filtering - Yes Audio Bit Rate - 64 Kbps(G.711 alaw) |
Battery And Power | |
Power Supply |
12V DC ± 5%, 5.5mm Coaxial Power Plug
PoE (802.3at, class 0) |
Power Consumption |
12V DC: Max 10.1W
PoE: Class 0 |
Power |
DC Power Port
|
Security | |
Security Feature |
Password Protection, HTTPS Encryption,
IP Address Filter, Digest Authentication |
Video Features | |
Video Resolution |
2688 x 1520
|
Video Quality |
Main Stream
Frame Rate 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps Resolution: 2688x1520, 2560x1440, 2304x1296, 2048x1280, 1920x1080, 1280x720 Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps. Sub-Stream Frame Rate: 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps Resolution: 704x576,640x480, 352x288, 320x240 Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps. Bit Rate Control CBR, VBR Video Compression Main Stream: H.265+/H.265/H.264+/H.264 Sub-Stream: H.265/H.264 H.264 Type Main Profile/High Profile H.264+ Main Stream Supported H.265 Type Main Profile H.265+ Main Stream Supported Video Bit Rate Main Stream: 256 Kbps to 6 Mbps Sub-Stream: 64 Kbps to 512 Kbps |
Special Features | |
Certifications |
CE, NTRA, VCCI, KC, BSMI, FCC, IC
|
Others | |
Button |
Yes
|
Other Features |
Angle Adjustment (Manual)
Range Pan: 0° to 348°, Tilt: 0° to 105° ILLUMINATOR IR LED Quantity: 2 Range: 30m Wavelength: 850nm White LED Quantity: 2 Range: 30m Illuminator On/Off Control Auto/Scheduled/Always on/Always off ALARM AND EVENT MANAGEMENT Smart Event Human & Vehicle Classification, Area Intrusion Detection, Line-Crossing Detection, People Detection, Vehicle Detection, Region Entering Detection, Region Exiting Detection, Object Abandoned Detection, Object Removal Detection, Loitering Detection Basic Event Motion Detection, Video Tampering Detection, Exception ( Illegal Login), Scene Change Detection Alarm Linkage Memory Card Video Recording, Message Push, Audible Warning, White Light Flashing Output Notification - Message Push Deep Learning Function People & Vehicle Analytics Search and filter to people or vehicle of interest based on many different attributes, making post-event search faster and easier. Multi-Target-Type Detection Supports Simultaneous Detection and Capture of Human Body and Vehicle On-board Storage Built-In Memory Card Slot, Support MicroSD Card, up to 256 GB PTZ Pan/tilt Range - Pan: 0° to 348°, Tilt: 0° to 105° Pan/tilt Speed Pan Speed: Configurable from 8° to 44°/s; Preset Speed: 44°/s Tilt Speed: Configurable from 8° to 44°/s, Preset Speed: 44°/s Manual Control Speed - Configurable from 8° to 35°/s Presets - 300 Patrol Scan - 8 patrols, up to 8 presets for each patrol Power-off Memory Yes; Auto restore to previous PTZ and lens status after power failure Park Action - Yes; Preset; Patrol Scan 3D Positioning - Yes Weatherproof Rating - IP67 Illumination Distance - 30 m |
Physical Specification | |
Color |
White
|
Package Contents |
VIGI Network Camera
Quick Start Guide Mounting Accessories |
Operating Humidity |
95% or Less (Non-Condensing)
|
Storage humidity |
95% or Less (Non-Condensing)
|
Materials |
Front Cover: Mental
Other: Plastic Front Cover: Metal Back Cover: Plastic |
Operating Temperature |
-30–60 °C
|
Dimension |
99 × 102 × 236 mm
|
Storage Temperature |
-40–60 °C
|
Technical Info | |
Model |
VIGI C340S
|
Warranty Information | |
Warranty |
1-Year
|
