Display | |
Image Sensor |
1/3” Progressive Scan CMOS
|
Image |
Image Settings
Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance, Prevent Overexposure to Infrared Light, HLC Adjustable by Client Software, Rotation(90°/270°) Image Enhancement: BLC/3D DNR/HLC/SmartIR Wide Dynamic Range: DWDR SNR: ≥ 52 dB Image Parameters Switch: Yes Privacy Mask: Up to 4 Masks ROI: 1 Region OSD Setting: Yes |
Viewing Angle |
2.8mm: 88.8°/48.9°/106.5°(H/V/D)
4mm: 75.1°/41.5°/88.7°(H/V/D) |
Camera | |
LENS |
Aperture: 2.8 mm: F2.2 & 4 mm: F2.2
FOV 2.8 mm: Horizontal FOV: 88.8°, Vertical FOV: 48.9°, Diagonal FOV: 106.5° 4 mm: Horizontal FOV: 75.1°, Vertical FOV: 41.5°, Diagonal FOV: 88.7° DORI Distance 2.8 mm: Detect:60 m (197 ft) Observe: 25 m (82 ft) Recognize: 12 m (39 ft) Identify: 6 m (20 ft) 4 mm: Detect: 80 m (262 ft) Observe:33 m (109 ft) Recognize: 16 m (52 ft) Identify: 8 m (26 ft) |
Lens type |
Fixed Focal Lens
|
Shutter Speed |
1/3 to 1/10000 s
|
Focal Length |
2.8 mm/ 4 mm
|
Networking & Connectivity | |
Networks |
Protocol: TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS,
RTSP, NTP, UPnP UDP, SSL/TLS ONVIF: Yes API: ONVIF Simultaneous Live View: 3 Main Streams & 3 Sub-Streams Client: VIGI App, VIGI Security Manager, VIGI NVR, Web Web Browser: Google Chrome 57 and above Firefox 52 and above Safari 11 and above Microsoft Edge 91 and above Cloud: Yes Security: Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication |
Battery And Power | |
Power Supply |
12V DC ± 5%, 5.5mm Coaxial Power Plug
PoE (802.3af/at, class 0) |
Power Consumption |
12V DC: Max 5W
PoE: Class 0 |
Video Features | |
Video |
Max. Resolution: 2560 × 1440
Main Stream Frame Rate: 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps Resolution: 2560x1440,2304x1296, 2048x1280, 1920x1080, 1280x720 Sub-Stream Frame Rate: 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps Resolution: 640x480,352x288, 320x240 Bit Rate Control: CBR, VBR Video Compression Main Stream: H.265+/H.265/H.264+/H.264 Sub-Stream: H.265/H.264 H.264 Type: Main Profile/High Profile H.264+: Main Stream Supported H.265 Type: Main Profile H.265+: Main Stream Supported Video Bit Rate Main Stream: 256 Kbps to 4 Mbps Sub-Stream: 64 Kbps to 512 Kbps |
Special Features | |
Certifications |
CE/BSMI/VCCI/ONVIF
|
Protection |
IP67, IK10
|
Features |
Two Streams, Mirror, Privacy Masks, Password Reset via E-mail, HTTP Listening
|
Smart Features |
Smart Event:
Human & Vehicle Classification, Intrusion Detection, Line-Crossing Detection, Human Detection, Vehicle Detection, Region Entering Detection, Region Exiting Detection, Object Abandoned Detection, Object Removal Detection Basic Event: Motion Detection, Camera Tampering Detection, Exception (Illegal Login) Linkage Method: Trigger Notification: ONVIF, HTTPS Region of Interest: 1 Region |
Others | |
Other Features |
Minimum Illumination: Color: 0.1 Lux; 0 Lux with IR
Day/Night Mechanism: IR Cut Filter Day/Night Switch: Unified/ Scheduled/ Auto Digital Noise Reduction: 3D DNR WDR: DWDR IR Working Distance: 30m |
Physical Specification | |
Package Contents |
VIGI Network Camera
Quick Start Guide Waterproof Cable Attachments Mounting Accessories |
Operating Humidity |
95% or Less (Non-Condensing)
|
Storage humidity |
-40–60 °C
|
Materials |
Plastic
|
Operating Temperature |
-30–60 °C
|
Dimension |
115 × 115 × 86 mm
|
Storage Temperature |
95% or Less (Non-Condensing)
|
Weight |
Net Weight: 0.27 Kg
Gross Weight: 0.45 Kg |
Technical Info | |
Brand |
TP-link
|
Model |
VIGI C240I
|
Warranty Information | |
Warranty |
1-Year
|
