Port Number | 24 × 10/100 Mbps PoE ports, 1 × gigabit RJ45 port, and 1 × gigabit fiber optical port | |
Port Type | RJ45 port, full duplex, MDI/MDI-X adaptive | |
Working Mode | Standard mode (default); Extend mode | |
Standard | IEEE 802.3, IEEE 802.3u, IEEE 802.3x | |
Forwarding Mode | Store-and-forward switching | |
Ports For Long-Distance Transmission | Ports 17 to 24 | |
MAC Address Table | 4k | |
Internal Cache | 2.75 Mbits | |
Switching Capacity | 8.8 Gbps | |
Packet Forwarding Rate | 6.547 Mpps | |
High Priority Ports | Ports 1 to 8 | |
PoE Standard | IEEE 802.3af, IEEE 802.3at | |
PoE Port | Ports 1 to 24 | |
Max. Port Power | 30 W | |
PoE Power Budget | 230 W | |
Long Range | Ports 17 to 24: up to 300 m; and the speed rate of the port is 10 Mbps. | |
Dimension (W × H × D) | 335 mm × 44.5 mm × 226 mm (13.2” × 1.8” × 8.9”) | |
Storage Temperature | -40 °C to 85 °C (-40 °F to 185 °F) |
PoE Management with Intelligence. PoE ports smartly regulate the power supply when it exceeds the limit, extending the switch's lifetime. Long-range PoE transmission up to 300 meters. The maximum distance between IPCs and switch is 300 meters. Adaptive Power Supply for 4/8 Cores with Low Power Loss The power loss on cables is reduced with an 8-core power supply. Surge Protection of 6KV to Improve Reliability in a Strenuous Environment In a hostile environment, the built-in surge protection device protects the switch from a sudden lightning surge. Video transmission design. When network congestion arises, the VIP port ensures crucial data transfer.
