Asus PRIME B450M-A AMD Gen 2 AM4 mATX motherboard

Stock : Out of Stock PID : P0122506020 SKU : TL-FDPRIMEB4DJ Brand : Asus Model : ASUS PRIME-B450M-A
1 Reviews
  • Chipset: AMD B450
  • Supported CPU: AMD AM4 Socket
  • ATX Form Factor 12 inch x 9.6 inch
  • LAN: Realtek RTL8111H
  • Asus PRIME B450M-A AMD

    ●︎ Fan Xpert 2+__Flexible controls for ultimate cooling and silence, plus GPU-temperature sensing for cooler gaming

    ●︎ Ultrafast connectivity__ Supreme flexibility with USB 3.1 Gen 2 and native M.2

    ●︎ ASUS Aura Sync header__ Onboard connector for RGB LED strips, easily synced with an ever-growing portfolio of Aura Sync-capable hardware

    ●︎ 5X Protection III__ Multiple hardware safeguards for all-around system protection

    **3 years replacement warranty

    ASUS Prime B450 Series motherboards provide the solid foundation needed for your first build, plus flexibility to grow with your ambitions. We've melded all the good stuff that's packed into AMD Ryzen™ processors with essential ASUS design and engineering, so you benefit from industry-leading technologies — including automated system tuning, comprehensive cooling controls, and immersive onboard audio. When you build with an ASUS Prime B450 Series motherboard, you build smart, easy and affordably.

    [product_table id="34" limit="10" type="filter" filter_category="7271"]

    Processor
    Supported CPU
    AMD AM4 Socket AMD Ryzen™ 2nd Generation/Ryzen™ with Radeon™ Vega Graphics/Athlon™ with Radeon™ Vega Graphics/Ryzen™ 1st Generation Processors
    Mainboard
    Chipset
    AMD B450
    BIOS
    256 Mb Flash ROM, UEFI AMI BIOS, PnP, WfM2.0, SM BIOS 3.0, ACPI 6.0, Multi-language BIOS,
    ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Last Modified log,
    F12 PrintScreen, Secure Erase, User Profile, F4 AURA ON/OFF, F9 Search, and ASUS DRAM SPD (Serial Presence Detect) memory information.
    Memory
    Memory
    AMD Ryzen™ 2nd Generation/ Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics/ Ryzen™ 1st Generation Processors
    Storage
    Supported Storage
    AMD B450 chipset :
    4 x SATA 6Gb/s port(s),
    Support Raid 0, 1, 10
    AMD Ryzen™ 2nd Generation/ Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics/ Ryzen™ 1st Generation Processors :
    2 x SATA 6Gb/s port(s),
    Support Raid 0, 1, 10
    AMD Ryzen™ 2nd Generation/ Ryzen™ with Radeon™ Vega Graphics/ Ryzen™ 1st Generation Processors :
    1 x M.2 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode)*2
    AMD Athlon™ with Radeon™ Vega Graphics Processors :
    1 x M.2 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support (SATA mode)*2
    Graphics
    Graphics
    Integrated Graphics in the AMD Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics Processors
    Multi-VGA output support : HDMI/DVI-D/D-Sub ports
    - Supports HDMI 2.0b with maximum resolution of 4096 x 2160 @ 60 Hz
    - Supports DVI-D with max. resolution 1920 x 1200 @ 60 Hz
    - Supports D-sub with max. resolution 1920 x 1200 @ 60 Hz
    Networking & Connectivity
    LAN
    Realtek® RTL8111H, 1 x Gigabit LAN Controller(s)
    ASUS LAN Guard
    Audio & Microphone
    Audio
    Realtek® ALC887 8-Channel High Definition Audio CODEC
    Audio Feature :
    - LED-illuminated design - Brighten up your build with the gorgeous illuminated audio trace path.
    - Audio Shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference
    - Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals
    - Premium Japanese audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity
    Ports
    Slots
    AMD Ryzen™ 2nd Generation/ Ryzen™ 1st Generation Processors
    1 x PCIe 3.0/2.0 x16 (x16 mode)
    AMD Ryzen™ with Radeon™ Vega Graphics Processor
    1 x PCIe 3.0/2.0 x16 (x8 mode) *1
    AMD Athlon™ with Radeon™ Vega Graphics Processors
    1 x PCIe 3.0/2.0 x16 (max at x4 mode)
    AMD B450 chipset
    2 x PCIe 2.0 x1)
    Internal I/O Ports
    1 x Aura RGB Strip Header
    1 x USB 3.1 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s) (19-pin)
    2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
    1 x M.2 Socket 3 with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode)
    1 x TPM header
    1 x COM port(s) connector(s)
    6 x SATA 6Gb/s connector(s)
    1 x CPU Fan connector(s) (1 x 4 -pin)
    2 x Chassis Fan connector(s) (2 x 4 -pin)
    1 x S/PDIF out header(s)
    1 x 24-pin EATX Power connector(s)
    1 x 8-pin ATX 12V Power connector(s)
    1 x Front panel audio connector(s) (AAFP)
    1 x System panel(s)
    1 x Clear CMOS jumper(s)
    1 x Speaker connector
    USB
    AMD Ryzen™ 2nd Generation/ Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics/ Ryzen™ 1st Generation Processors :
    4 x USB 3.1 Gen 1 port(s) (4 at back panel, blue)
    AMD B450 chipset :
    2 x USB 3.1 Gen 2 port(s) (2 at back panel, )
    AMD B450 chipset :
    2 x USB 3.1 Gen 1 port(s) (2 at mid-board)
    AMD B450 chipset :
    4 x USB 2.0/1.1 port(s) (4 at mid-board)
    Physical Specification
    Form Factor
    ATX Form Factor
    12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
    Warranty Information
    Warranty
    03 years
    1. Tazwar Tasim
      Onk vlo MoBo. Apnara nite paren
      25 November, 2022

    Write A Review

    What is the Asus PRIME B450M-A AMD Gen 2 AM4 mATX motherboard Price in Bangladesh 2025 ?

    The Asus ASUS PRIME-B450M-A Price in BD is 12,500৳ . This Asus PRIME B450M-A AMD Gen 2 AM4 mATX motherboard Manufacturing by Asus Comes With Warranty & Based on 0 reviews. Tech Land BD Offers you Asus ASUS PRIME-B450M-A by 12,500৳ and its regular price is 13,500৳ Which is also Out of Stock Now at our Showroom. Follow us on Facebook For Regular updates & Offer. Subscribe Our YouTube Channel for Product Reviews.
