Asus PRIME B450M-K II DDR4 AMD AM4 mATX Motherboard, now available at TechLand BD, designed to deliver exceptional performance and reliability for your gaming and computing needs in Bangladesh. Compatible with a wide range of AMD processors, including Ryzen 5000 Series, 5000 G-Series, 4000 G-Series, and various other Ryzen and Athlon models, this motherboard ensures seamless compatibility and efficient operation. Powered by the AMD B450 chipset and equipped with a 256 Mb Flash ROM UEFI AMI BIOS, it offers stability and flexibility for your system configurations. The mATX form factor, measuring 8.9 inches by 8.7 inches (22.6 cm x 22.1 cm), provides a compact yet feature-rich platform for your build. With expansion slots including PCIe 3.0 x16 and PCIe 2.0 x1, along with support for M.2 storage and SATA 6Gb/s ports, it offers ample connectivity options for your components. The motherboard supports dual-channel DDR4 memory technology with speeds up to 4400 MHz (OC), allowing for smooth multitasking and efficient data processing. Integrated graphics support includes HDMI 2.0b, D-Sub, and DVI-D ports, catering to various display configurations. Connectivity features include rear USB ports with USB 3.2 Gen 1 and USB 2.0, as well as LAN support via Realtek RTL8111H and ASUS LANGuard. The Realtek ALC887/897 7.1-Channel High Definition Audio CODEC delivers immersive sound quality, enhanced by LED-illuminated design and premium Japanese audio capacitors. Internal I/O ports include CPU and chassis fan connectors, USB headers, SPI TPM header, COM port connectors, SATA connectors, and more, ensuring easy installation and customization. With a manufacturing warranty of 3 years, the Asus PRIME B450M-K II motherboard offers peace of mind and reliability for your computing needs. Elevate your gaming and computing experience with the Asus PRIME B450M-K II DDR4 AMD AM4 mATX Motherboard, now available at TechLand BD.
Processor | |
Supported CPU |
AMD AM4 Socket for AMD Ryzen 5000 Series/ 5000 G-Series/ 4000 G-Series/ 3rd/2nd/1st Gen AMD Ryzen/ 2nd and 1st Gen AMD Ryzen with Radeon Vega Graphics/ Athlon with Radeon Vega Graphics Processors
|
Mainboard | |
Chipset |
AMD B450
|
BIOS |
256 Mb Flash ROM, UEFI AMI BIOS
|
Memory | |
Memory Specifications |
4400(O.C)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/ 3400(O.C.)/3300(O.C.)/3200(O.C.)/3000(O.C.)/2933(O.C.)/2800(O.C.) / 2666/2400/2133 MHz Un-buffered Memory
|
Memory Type |
Dual Channel DDR4 Memory Technology
|
Max. Memory Size |
64GB
|
Storage | |
Storage |
Total supports 1 x M.2 slot(s) and 4 x SATA 6Gb/s ports
3rd/2nd/1st Gen AMD Ryzen/ 2nd and 1st Gen AMD Ryzen with Radeon Vega Graphics : 1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (SATA & PCI-E 3.0 x 4 mode) Athlon with Radeon Vega Graphics Processors : 1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (SATA mode) AMD B450 chipset : 4 x SATA 6Gb/s port(s), Support Raid 0, 1, 10 |
Graphics | |
Graphics |
Integrated Graphics in the 2nd and 1st Gen AMD Ryzen with Radeon Vega Graphics/ Athlon with Radeon Vega Graphics Processors
1 x D-Sub 1 x DVI-D 1 x HDMI 2.0b |
Networking & Connectivity | |
LAN |
Realtek RTL8111H
ASUS LANGuard |
Audio & Microphone | |
Audio |
Realtek ALC887/897 7.1-Channel High Definition Audio CODEC
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking, up to 24-Bit/192kHz playback Audio Feature : - LED-illuminated design - Audio Shielding - Dedicated audio PCB layers - Premium Japanese audio capacitors Choose the chassis with an HD audio module in the front panel to support 8-channel audio output. |
Ports | |
PCI Card Slot |
3rd/2nd/1st Gen AMD Ryzen Processors
1 x PCIe 3.0 x16 (x16 mode) 2nd and 1st Gen AMD Ryzen with Radeon Vega Graphics Processors 1 x PCIe 3.0 x16 (x8 mode) AMD Athlon with Radeon Vega Graphics Processors 1 x PCIe 3.0 x16 (x4 mode) AMD B450 chipset 2 x PCIe 2.0 x1 |
Slots |
2 x DIMM
|
Internal I/O Ports |
1 x CPU Fan connector(s) (1 x 4 -pin)
1 x Chassis Fan connector(s) (1 x 4 -pin) 1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s) (19-pin) 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s) 1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode) 1 x SPI TPM header 1 x COM port(s) connector(s) 4 x SATA 6Gb/s connector(s) 1 x S/PDIF out header(s) 1 x 24-pin EATX Power connector(s) 1 x 8-pin ATX 12V Power connector(s) 1 x Front panel audio connector(s) (AAFP) 1 x System panel(s) 1 x Clear CMOS jumper(s) 1 x COM port header 1 x Speaker connector |
USB |
Rear USB Port ( Total 6 )
4 x USB 3.2 Gen 1 port(s)(4 x Type-A) 2 x USB 2.0 port(s)(2 x Type-A) Front USB Port ( Total 6 ) 2 x USB 3.2 Gen 1 port(s) 4 x USB 2.0 port(s) |
HDMI |
1 x HDMI 2.0b
|
Others | |
Other Features |
M.2 Socket:
Total supports 1 x M.2 slot(s) and 4 x SATA 6Gb/s ports 3rd/2nd/1st Gen AMD Ryzen/ 2nd and 1st Gen AMD Ryzen with Radeon Vega Graphics : 1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (SATA & PCI-E 3.0 x 4 mode) Athlon with Radeon Vega Graphics Processors : 1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (SATA mode) AMD B450 chipset : 4 x SATA 6Gb/s port(s), Support Raid 0, 1, 10 TPM (Trusted Platform Module ): 1 x SPI TPM header |
Physical Specification | |
Form Factor |
mATX Form Factor
8.9 inch x 8.7 inch ( 22.6 cm x 22.1 cm ) |
Warranty Information | |
Warranty |
3 Years
|
