The Ezviz CS-CB3 is a 2.0MP 2.8mm Wi-Fi Battery Operated Security Camera available at TechLand BD. This outdoor IP camera is designed with a fixed lens and a 1/2.9 inch image sensor that provides a maximum resolution of 1920 x 1080. The camera features a self-adaptive shutter and an IR-Cut filter with auto-switching for day and night vision. The 2.8mm lens offers an 8x zoom and a 128-degree diagonal viewing angle. The camera’s general functions include anti-flicker, heart beat, password protection, and watermark. It operates at a frame rate of 15fps and has 3D digital noise reduction (DNR). The camera interfaces with a microSD card and supports Wi-Fi connectivity with IEEE802.11b, 802.11g, 802.11n standards.
It pairs via AP pairing and offers security features such as 64 / 128 bit WEP, WPA / WPA2, WPA-PSK / WPA2-PSK encryption, password protection, and watermark. The camera also supports motion detection and human detection, and is dust, water, and weatherproof. It can provide simultaneous live view. The camera uses H.265 / H.264 video type and has both a mic and speaker for 2-way audio communication. It operates at a frequency of 2.4 GHz - 2.4835 GHz and has a working distance of 15 meters. The camera uses the EZVIZ Cloud Proprietary Protocol. The bullet form-factor camera has a smart human motion detection alarm and a microSD card slot. It supports up to 256GB of storage. The camera is black & white in color and measures 105.9 x 62.8 x 62.8mm. It weighs 480 gm and operates on a DC 5V power supply with an approximate power consumption of 10W. It can operate in temperatures from -20 to 50 degrees C and in humidity of 95% or less (non-condensing). The camera comes with a 1-year warranty from TechLand BD.
Display | |
Image Sensor |
1/2.9 Inch
|
Image |
Anti-Flicker, Heart Beat, Password Protection, Watermark
|
Viewing Angle |
128 Degree (Diagonal)
|
Camera | |
Camera |
IP Camera
|
Camera Resolution |
1920 x 1080
|
LENS |
2.8mm
|
Networking & Connectivity | |
WiFi |
IEEE802.11b, 802.11g, 802.11n
|
Audio & Microphone | |
Mic |
Both Mic and Speaker
|
Battery And Power | |
Power Supply |
DC 5V
|
Recommended Power |
10W
|
Video Features | |
Video |
H.265 / H.264
|
Special Features | |
Zoom |
8x
|
Others | |
Other Features |
Night Vision Mode
Frame Rate 15fps |
Physical Specification | |
Color |
Black & White
|
Operating Humidity |
95% or less (Non-condensing)
|
Dimension |
105.9 x 62.8 x 62.8mm
|
Weight |
480 gm
|
Technical Info | |
Range |
15 Meter
|
Frequency Response |
2.4 GHz - 2.4835 GHz
|
Type |
Fixed
|
Warranty Information | |
Warranty |
1 year
|
