DSPPA D6284 Video Conference Camera

DSPPA D6284 Video Conference Camera in Bangladesh

The DSPPA D6284 is a high-performance video conference camera designed for professional video conferencing, live streaming, and broadcasting environments. With its 1/2.8-inch CMOS sensor delivering a crisp 2.14 megapixel resolution, this camera ensures superior image quality in full HD 1080p at up to 60 frames per second. Equipped with a powerful 20x optical zoom lens (f=4.7mm~94mm), it provides a dynamic field of view ranging from 59.5° wide angle to a narrow 2.9°, enabling users to capture everything from wide-room coverage to precise close-ups effortlessly. Advanced imaging technologies such as 2D/3D digital noise reduction, wide dynamic range (WDR), and backlight compensation help maintain clarity and detail in challenging lighting conditions. The camera supports both automatic and manual control for focus, exposure, gain, and white balance—ensuring flexibility across diverse shooting environments. The intelligent PTZ (Pan-Tilt-Zoom) mechanism allows for smooth, accurate movements with 256 programmable presets and rotation speeds up to 120°/s horizontally and 80°/s vertically. The D6284 is equipped with versatile connectivity options, including HDMI, 3G-SDI, USB 3.0, and an RJ-45 network port. It supports video output formats such as H.264, H.265, MJPEG, and more, with compatibility for ONVIF, RTSP, RTMP, SRT, and NDI (optional), making integration into existing systems seamless. The USB interface supports UVC 1.1 for plug-and-play ease with major conferencing platforms, while audio input via a 3.5mm LINE IN jack and UAC PCM support ensures high-quality sound. For control and automation, it includes RS-232/RS-485 interfaces and supports VISCA and PELCO-P/D protocols, with daisy-chaining capability. Designed for reliability, it operates efficiently within a 0–40°C temperature range and 10–90% humidity. Its sleek silver-gray chassis, compact 242×145×163mm dimensions, and lightweight build (≤1.2kg) make it ideal for discreet installation in professional settings. Whether for business conferencing, distance learning, or media production, the DSPPA D6284 delivers exceptional performance, flexibility, and value.

FAQs:

1. What platforms and software are compatible with the DSPPA D6284?

The DSPPA D6284 supports UVC 1.1 via its USB 3.0 interface, making it plug-and-play with most major video conferencing platforms such as Zoom, Microsoft Teams, Skype, Google Meet, and OBS. It also supports standard video streaming protocols (RTSP, RTMP, SRT) for integration with live broadcasting and media servers.

2. Can the D6284 be mounted upside down or on the ceiling?

Yes, the DSPPA D6284 supports inverted installation. It includes an image flip feature, which ensures the video remains correctly oriented when the camera is mounted upside down or on the ceiling.

3. Does the camera support remote control and preset positions?

Yes, the D6284 includes support for RS-232 and RS-485 control interfaces and is compatible with VISCA, PELCO-P, and PELCO-D control protocols. It supports up to 256 programmable preset positions, allowing for quick and precise camera angle changes during use.
